Lampro LXII Pro 4.0
8,000 nits at 4 mm — sharp enough for close-range city sites like Durbar Marg and still readable at midday.
Cabinet front elevation — emitter grid and module seams drawn to scale.
Manufacturer product photography. Photography of the delivered installation is included in every project handover.
Pixel pitch
P4
Brightness
8,000 nits
Refresh
3,840 Hz
Use
Outdoor
How it connects
Your source to this wall
Every Lampro wall we supply ships as a complete signal chain \u2014 including the NovaStar control layer most suppliers leave for you to figure out.
How it connects
source
Source (PC / player / camera)
processor
NovaStar MX30
controller
Sending & receiving cards
wall
Lampro LXII Pro 4.0
Engineering
Major features, part by part
Hover any numbered point to see what it does and why it matters on site.
Reference
Typical wall sizes
Cabinets, resolution, power and weight for common wall sizes built from the 960×960 mm Lampro cabinet at P4.
| Target size | Cabinets | Resolution | Actual size | Avg power | Weight |
|---|---|---|---|---|---|
| 3 × 2 m | 3 × 2 (6) | 720 × 480 (0.3 MP) | 2.88 × 1.92 m | 2.2 kW | 162 kg |
| 4 × 2.5 m | 4 × 3 (12) | 960 × 720 (0.7 MP) | 3.84 × 2.88 m | 4.5 kW | 324 kg |
| 5 × 3 m | 5 × 3 (15) | 1200 × 720 (0.9 MP) | 4.80 × 2.88 m | 5.6 kW | 405 kg |
| 6 × 3.5 m | 6 × 4 (24) | 1440 × 960 (1.4 MP) | 5.76 × 3.84 m | 9.0 kW | 648 kg |
| 8 × 4.5 m | 8 × 5 (40) | 1920 × 1200 (2.3 MP) | 7.68 × 4.80 m | 14.9 kW | 1080 kg |
| 10 × 6 m | 10 × 6 (60) | 2400 × 1440 (3.5 MP) | 9.60 × 5.76 m | 22.4 kW | 1620 kg |
Cabinet counts are rounded to whole cabinets, so the actual size differs slightly from the target. Power is the average draw; size the supply on peak. Confirm structural loading against the manufacturer datasheet.
Why this model
IP65 front & rear
Sealed against monsoon rain and dust, year-round.
Smart dimming
Light sensors auto-adjust brightness and cut power cost at night.
Sunlight readable
High-nit output keeps content legible in direct sun.
Where this goes
Typically specified for roadside billboards and city signage
Specifications
Applications
FAQ
How bright do I need outdoors?
6,000–10,000 nits for direct sun; it auto-dims after dark.
Will it survive monsoon?
Yes — IP65 sealing front and rear, with drainage and coated boards.
Will it look sharp?
Viewing distance & image quality
Minimum viewing distance
4 m
Closest a viewer should stand
Comfortable distance
10 m
Where the image looks its best
Pixels per m²
62,500
Density at this pitch
Brightness
8,000 nits
Daylight readable
Rule of thumb: minimum viewing distance in metres \u2248 pixel pitch in millimetres. Final figures confirmed on site survey.
What you actually receive
A complete system, not just panels
LED cabinets & modules
Lampro LXII Pro 4.0 · 960×960 mm
Control system
NovaStar MX30 + receiving cards
Power & data cabling
Looms, distribution and redundancy
Mounting structure
Wall frame, floor stand or truss
Spare modules & PSU
Held in Kathmandu for fast swap
Commissioning
Calibration, content test, handover training
How we deliver it
Site survey
We measure the space, power and sightlines — free across Nepal.
Structure & install
Fabrication, mounting and cabling by our certified engineers.
Commissioning
Calibration, controller setup and operator training.
AMC & support
Annual maintenance with spares stocked locally.
Warranty
Up to 3 years
Honoured locally in Nepal
Indicative lead time
2\u20134 weeks
Ex-stock items ship faster
Certifications
Also consider
| Model | Pitch | Brightness | Use | Cabinet |
|---|---|---|---|---|
| Lampro LXII Pro 4.0 (this model) | P4 | 8,000 nits | outdoor | 960\u00d7960 mm |
| Lampro LS Pro Perimeter 4 | P4 | 7,000 nits | outdoor | 1600\u00d7900 mm |
| Lampro RNII O 3.91 | P3.91 | 4,000 nits | rental | 500\u00d71000 mm |
| Lampro Lmate RM 3.9 | P3.9 | 1,300 nits | rental | 500\u00d7500 mm |
The full Lampro line
Lampro product lines we supply
Lampro and Unilumin are sister brands within the same group, built on the same engineering and the same quality system. Lampro covers COB fine pitch, DOOH-grade outdoor, rental staging and transparent, and is the line that most often clears a Nepali government tender on price without dropping certification — because the group standard behind it is the same one behind Unilumin.
Need a drawing, availability or the manufacturer datasheet for Lampro LXII Pro 4.0?
Talk to an engineer →
